Product Summary

The LM4853MM is an audio power amplifier capable of delivering 1.5W (typ) of continuous average power into a mono 4Ω bridged-tied load (BTL) with 1% THD+N or 95mW per channel of continuous average power into stereo 32Ω singleended (SE) loads with 1% THD+N, using a 5V power supply. It can automatically switch between mono BTL and stereo SE modes utilizing a headphone sense pin. It is ideal for any system that provides both a monaural speaker output and a stereo line or headphone output. The LM4853MM is used in Portable computers, Desktop computers, PDAs, Handheld games, etc.

Parametrics

Absolute maximum ratings: (1)Supply Voltage: 6.0V; (2)Storage Temperature: 65°C to +150°C; (3)ESD Susceptibility (Note 4: 3.5kV; (4)ESD Machine model (Note 7): 250V; (5)Junction Temperature (TJ): 150°C; (6)Small Outline Package:Vapor Phase (60 sec.): 215°C;Infrared (15 sec.): 220°C; (7)Thermal Resistance:θJA (typ)—MUB10A: 194°C/W;θJC (typ)—MUB10A: 52°C/W;θJA (typ)—LDA14A (Note 10): 56°C/W;θJC (typ)—LDA14A: 4.3°C/W.

Features

Features: (1)Mono 1.5W BTL or stereo 300mW output; (2)Headphone sense; (3)“Click and pop” suppressiocircuitry; (4)No bootstrap capacitors required; (5)Thermal shutdowprotection; (6)Unity-gaistable; (7)Available ispace-saving MSOP and LLP packaging.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
LM4853MM/NOPB
LM4853MM/NOPB
National Semiconductor (TI)
Audio Amplifiers
Data Sheet
0-1: $1.37
1-25: $1.05
25-100: $0.95
100-250: $0.86
LM4853MMX
LM4853MMX
National Semiconductor (TI)
Audio Amplifiers
Data Sheet
0-3500: $0.53
3500-7000: $0.51
7000-10500: $0.49
LM4853MMX/NOPB
LM4853MMX/NOPB
National Semiconductor (TI)
Audio Amplifiers
Data Sheet
0-2420: $0.57
2420-2500: $0.53
2500-3500: $0.53
3500-5000: $0.51
LM4853MM
LM4853MM
National Semiconductor (TI)
Audio Amplifiers
Data Sheet
0-1000: $0.56
1000-3000: $0.53
3000-5000: $0.51
5000-10000: $0.49
